Low temperature chiller for lab industrial water chiller heating and chilling equipment with digital display cooling water bath

FOB Reference Price:Get Latest Price
$5,000.00 - $15,000.00 / Set | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 2 - 2 3 - 3 >3
Est. Time(days) 10 20 30 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets)
OEM ODM (Min. Order: 1 Sets)
Explosion-proof Devices (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Classification:
Laboratory Thermostatic Devices
Brand Name:
XINCHEN
Model Number:
HRB-250V
Place of Origin:
Jiangsu, China
Product name:
Heating Refrigerated Circulator
Temperature Range:
-50~250 degree
Pump flowrate:
110L/min
Pressure:
1.5bar
Heating Power:
25Kw
Pump:
Magnetic drive circulation pump
Compressor:
American or France TECUMSEH
Display:
Digital LCD Display
Protections:
Overload protection , overheat protection, overcurrent protection
Temperature probe:
PT100 Probe
Supply Ability
Supply Ability:
200 Set/Sets per Month Max annual output 2400 sets , min output 2000 sets factory price
Packaging & Delivery
Packaging Details
Qualified export wooden case ,The equipment is wrapped with bubble film, and then the bubble film is wrapped on the machine with tape . In this way , it reduces the damage to the minimum during the transit and provide a good protection for the equipment .
Meanwhile , the wires are well placed on the top of the machine .
Port
Port of departuring: Nanjing / Ningbo/ Shanghai
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 2 - 2 3 - 3 >3
Est. Time(days) 10 20 30 To be negotiated
Video Description
Product Description
Lab equipment low temperature refrigerated chilling ethanol chiller also know as low temperature cooling water / liquid circulation pump, recirculating chillers, refrigerated circulator, circulation chiller, water chiller or recirculating chiller, This device adopt mechanical refrigeration, the main function is provide low temperature liquid for other device to achieve low temperature condition, usually are used wherever heat needs to be dissipated reliably and fast, e. g. in laboratories for rotary evaporators, distillation systems ,condenser, jacketed glass reactor or analytical devices.
Product Advantages & Features ◎The design of full closed pipeline, adopt high efficiency plate heat exchanger, reducing the demand for heat conduction fluid while providing the system's heat utilization rate, to achieve temperature rapid rise and fall ◎The use of feedforward adaptive programmable controller, can accurately control the temperature of the reactor material, and the system in the control process, no overshoot, no callback ◎Can store up to write a 120 set of programs, and each program can be written in 100 paragraph, fully guaranteed to meet the temperature requirement in the case of different materials. The user only need to according to the different materials call out procedures, then could achieve accurate temperature control, avoid the process of manual operation, improving the stability of product. ◎5.3 inch color touching screen display and input; control system provide: USB interface, RS232 interface, PT100 input interface, fault alarm output interface ◎Temperature process control charts can be displayed in high resolution color touch screen, including oil temperature, set the target value, the reactor material control temperature value, easy to query the whole process control. Using the USB data storage interface, as long as directly insert USB flash disk, the whole process of temperature control, data could record. ◎Fully closed design of heat conducting oil circulation pipeline, no oil mist and water absorption, to ensure the safety of the experiment and the life of the conductive fluid; ◎Refrigeration unit using France TECUMSEH compressor, high temperature magnetic drive circulation pump, stable performance, reliable quality; ◎It has the function of self-diagnosis; Refrigerator overload protection; high pressure switch, overload relay and thermal protection device etc. multiple security functions ◎High lift design to meet long distance transmission medium ◎Using a variety of environmentally friendly refrigerants to meet environmental requirements.
Product Applications
The heating and cooling circulator is used for supporting glass reaction kettle, rotary evaporator, fermentation tank and
calorimeter. It is widely used in petroleum, chemical industry, metallurgy, medicine, biochemistry, physical property, testing,
chemical analysis and other research departments, colleges and universities, factory laboratories and measurement and quality inspection departments.

Product Paramenters
Model
Temperature range(℃)
Pump flow (L/min) pressure(bar)
Heating(KW)
cooling capacity(KW)
250℃
200℃
100℃
0℃
-20℃
-30℃
HRB-25
-25~200
25; 1.5
2.5
/
2.5
2.5
1.5
1
/
HRB-35
-25~200
35; 1.5
3.5
/
3.5
3.5
3
2.1
/
HRB-50
-25~200
35; 1.5
5
/
5
5
4.5
2.8
/
HRB-70
-25~200
35; 1.5
7
/
7
7
6.2
4.2
/
HRB-100
-25~200
50; 1.5
10
/
10
10
8
6
/
HRB-150
-25~200
50; 1.5
15
/
15
15
13
9
/
HRB-180
-25~200
75; 1.5
18
/
18
18
15
11
/
HRB-250
-25~200
110; 1.5
25
/
25
25
21
15
/
HRB-25V
-50~250
25; 1.5
3.5
3.5
3.5
2.6
2
0.9
0.2
HRB-35V
-50~250
35; 1.5
5
5
5
3.5
3.1
1.2
0.5
HRB-50V
-50~250
35; 1.5
7
7
7
5.5
4.3
2
0.8
HRB-70V
-50~250
35; 1.5
10
10
10
7.5
6.2
2.3
1
HRB-100V
-50~250
50; 1.5
15
15
15
10
8.8
3.2
1.3
HRB-150V
-50~250
75; 1.5
18
18
18
15
11
6
4.8
HRB-250V
-50~250
110; 1.5
25
25
25
25
10
10
6.7
Details Images
Packaging & Shipping
Packaging: Standard carton package and wooden case package with inner protections( light weight material with protective ) . Some foam boards and bubble films wil be put into the inner package for any damage or other breakage with human wrong handling in loading and uploading . Shipping: By sea or by air as you wishes .( TNT , UPS , FedEx , EMS , DHL , SF or other logistics ) .
